German Type XXI in 1:72 Scale
  • German Type XXI in 1:72 Scale

    NOTE: The vendor of this product has let me know that due to high demand, new orders will not be able to ship for a minimum of 30 days from receipt of payment. Thanks for your patience and understanding.



    This model is available either as a physically 3D printed model kit or as 3D files that also include decals, hardware and photoetch. Please make your selection when you add to your cart.


    Files and details parts (no printed parts): $190

    Completely printed kit with decals, photoetch and hardware: $485



    Click here to download a sample hull section you can print to check for size and quality on your printer.



    Boat Background:

    Type XXI submarines were a class of German diesel–electric Elektroboot (German: "electric boat") submarines designed during the Second World War. One hundred and eighteen were completed, with four being combat ready. During the war only two were put into active service and went on patrols, but these were not used in combat.



    They were the first submarines designed to operate primarily submerged, rather than spending most of their time as surface ships that could submerge for brief periods as a means to escape detection. They incorporated many batteries to increase the time they could spend submerged, to as much as several days, and they only needed to surface to periscope depth for recharging via a snorkel. The design included many general improvements as well: much greater underwater speed by an improved hull design, greatly improved diving times, power-assisted torpedo reloading and greatly improved crew accommodations.

    After the war, several navies obtained XXIs and operated them for decades in various roles and large navies introduced new submarine designs based on them. These include the Soviet Whiskey, US Tang, UK Porpoise and Swedish Hajen classes, all based on the Type XXI design to some extent.



    Model Kit:

    This kit is composed of 3D printed sections, engineered for exceptionally easy assembly. Includes full brass photoetch detail part sheets and full-color decals.


    Many tower variants are available. Please select at time of checkout and the appropriate tower, brass and decals will be supplied with your order.



    Length: 42 inches (106cm)

    Beam: 4.3 inches (11cm)





    • Full-sized boat specifications

      General characteristics
      Class and type: Submarine
      Displacement:
      • 1,621 t (1,595 long tons) surfaced
      • 1,819 t (1,790 long tons) submerged[1]
      Length: 76.70 m (251 ft 8 in)[1]
      Beam: 8 m (26 ft 3 in)[1]
      Draught: 6.32 m (20 ft 9 in)[1]
      Propulsion:
      • Diesel/Electric
      • 2× MAN M6V40/46KBB supercharged 6-cylinder diesel engines, 4,000 PS (3,900 shp; 2,900 kW)
      • 2× SSW GU365/30 double-acting electric motors, 5,000 PS (4,900 shp; 3,700 kW)[1]
      • 2 × SSW GV232/28 silent running electric motors, 226 PS (223 shp; 166 kW)
      Speed:
      • 15.6 knots (28.9 km/h; 18.0 mph) surfaced
      • 17.2 knots (31.9 km/h; 19.8 mph) submerged[1]
      • 6.1 knots (11.3 km/h; 7.0 mph) (silent running motors)
      Range:
      • 15,500 nmi (28,700 km; 17,800 mi) at 10 knots (19 km/h; 12 mph) surfaced
      • 340 nmi (630 km; 390 mi) at 5 knots (9.3 km/h; 5.8 mph) submerged[1]
      Test depth: 240 m (787 ft)[1]
      Complement: 5 officers, 52 enlisted men[3]
      Armament:
      • 6 × 53.3 cm (21 in) torpedo tubes (bow)
      • 23 G7 torpedoes (or 17 torpedoes and 12 mines)
      • 4 x 2 cm (0.79 in) C/30 anti-aircraft guns [3]
